| System | ||
| Main Processor | Embedded processor |
|
| Operating System | Embedded linux |
|
| Audio and Video | ||
| IP Camera Input | 16+2 channels, each channel up to 6MP |
|
| Two-Way Talk | Reuse audio in/out, RCA |
|
| Display | ||
| Interface | 1 HDMI; 1 VGA | |
| Resolution | 1920 × 1080, 1280 × 1024, 1280 × 720 |
|
| Multi-Screen Display | When IP extension mode not enabled: 1/4/8/9/16 When IP extension mode enabled: 1/4/8/9/16 |
|
| OSD | Camera title; Time; Video loss; Camera lock; Motion detection; Recording |
|
| Recording | ||
| Compression | AI Coding/H.265+/H.265/H.264+/H.264 |
|
| Resolution | 1080N; 720p; 960H; D1; HD1; BCIF; CIF; QCIF |
|
| Record Rate | Main Stream: the 1st channel 1080N/720p (1 fps–25/30 fps), others 1080N/720p (1 fps–15 fps); 960H/D1/HD1/BCIF/CIF/QCIF (1 fps–25/30 fps) Sub stream: CIF/QCIF (1 fps–7 fps) |
|
| Bit Rate | 32 kbps–4096 kbps per channel |
|
| Record Mode | Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop | |
| Record Interval | 1 min–60 min (default: 60 min), Pre-record: 1 sec–30 sec, Post-record: 10 sec–300 sec |
|
| Video Detection And Alarm | ||
| Trigger Event | Recording; PTZ; Tour; Video Push; Email; FTP; Snapshot; Buzzer and Screen Tips |
|
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
|
| Playback And Backup | ||
| Sync Playback | 1/4/9/16 | |
| Playback Function | Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom | |
| Backup Mode | USB Device/Network |
|
| Search Mode | Time/Date, Alarm, MD and Exact Search (accurate to second) |
|
| Network | ||
| Interface | 1 RJ-45 Port (100 MB) |
|
| Maximum User Access | 128 users |
|
| Smart Phone | iPhone; iPad; Android |
|
| Network Function | HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; P2P; IP Search (Supports Dahua IP camera, DVR, NVS, etc.) | |
| Interoperability | ONVIF 16.12, CGI Conformant |
|
| Storage | ||
| Internal HDD | 1 SATA port, up to 6 TB capacity |
|
| Auxiliary Interface | ||
| USB | 2 USB ports (USB 2.0) |
|
| Power | ||
| Power Supply | DC 12V/2A |
|
| Power Consumption | < 10W |
|
| Component Environment | ||
| Operational Conditions | -10°C to +45°C (+14°F to +113°F), 10%–90% (RH) |
|
| Storage Conditions | -20°C to +70°C (-4°F to +158°F), 0%–90% (RH) |
|
| Construction | ||
| Dimensions | Compact 1U, 260.0 mm × 231.4 mm × 47.6 mm (10.24'' × 9.11'' × 1.87'') |
|
| Net Weight | 0.89 kg (1.96 lb) |
|
| Gross Weight | 1.42 kg (3.13 lb) |
|
The Dahua XVR1B16-I is a stand-alone recorder that captures HDMI videos as you watch them, without the need for a PC. Be it your games or sports games, Dahua DH-XVR1B16-I records HDMI video at the press of a button or on a schedule, even when your TV is powered off. With the remote control, view the recorded videos at your leisure. The snapshot function lets you capture your favorite moments into inspiring, high-quality pictures. The Dahua DH-XVR1B16-I makes post-production easy as well. The built-in video editor allows you to trim and merge clips seamlessly without a PC. Knowing you'll have the final touch just makes recording so much easier. The Dahua XVR1B16-I comes with a 1-year warranty.
